Description
- Single-stage operation (on/off)
- Compatible with any type of combustion chamber.
- High-pressure mechanical atomisation of fuel using a nozzle.
- Ability to obtain optimal combustion values by regulating combustion air and blast-pipe.
- Maintenance is facilitated by the fact that the atomisation unit can be removed without removing the burner from the boiler.
- Manual air flow adjustment.
- It comes with a 7-pole connector, 2 flexible oil pipes, 1 nozzle, 1 oil filter, 1 flange, and 1 insulating seal to connect the burner to the application.
Two-stage operation (high/low flame)
- Compatible with any type of combustion chamber.
- High blowing efficiency, low electrical input, low noise.
- High-pressure mechanical atomisation of fuel using a nozzle.
- Ability to obtain optimal combustion values by regulating combustion air and blast-pipe.
- The combustion head partially recycles combusting gas, allowing low NOx emissions (Class II for BTG 15 ME and Class III for BTG 20 ME of the European norm EN267).
- Maintenance is facilitated by the fact that the atomisation unit can be removed without having to remove the burner from the boiler.
- Air flow regulation for first and second stages by means of hydraulic jack.
- It comes with 4—and 7-pole connectors, 2 flexible oil pipes, 2 nozzles, 1 flange, and 1 insulating seal to connect the burner to the application.
Download Technical Manual
